Key Features
BMS Communication
Quarelex charger can communicate with quarelex forklift battery's BMS through CAN, and automatically stop charging when BMS gives 100% SOC feedback or charge current drop to less than set value.
>95% Efficiency
Overall AC-DC energy efficiency above 95%.
Wide AC Input Voltage
Single phase input voltage range: 110 / 230 V (90-264 V), 47-63 Hz, L+N+PE.
Three phase input voltage range: 380 / 480 V (303 ~ 530 V), 47-63 Hz, 3L + PE.
Wide DC Output Voltage
24V Charger output DC voltage range: 18 - 33 V
48V Charger output DC voltage range: 20 - 60 V
80V Charger output DC voltage range: 20 - 100 V
Full-range Protection
Overcharge, Over-discharge, Over voltage, Under voltage, Over current, Short Circuit, Over temperature, Under temperature, etc.
Key Specifications
Compatible Battery Voltage: 24 - 96V
Max Current: 50 - 400A
Efficiency: >95%
IP Grade: IP20
Remote Monitoring: Wifi Optional
Warranty: 2 years
Charger Model | AC Input Voltage, Hz, Wiring | Rated Output DC Voltage | Output DC Voltage Range | Output DC Current | Connector |
| 24V Series | |||||
| QC24-100 | 90-264 V, 47-63 Hz, L+N+PE | 24 V | 5-30 V | 100 A | REMA/Anderson/Customized |
| QC24-200 | 90-264 V, 47-63 Hz, L+N+PE | 24 V | 18-33 V | 200 A | REMA/Anderson/Customized |
| 48V Series | |||||
| QC48-50 | 90-264 V, 47-63 Hz, L+N+PE | 48 V | 5-60 V | 50 A | REMA/Anderson/Customized |
| QC48-100 | 90-264 V, 47-63 Hz, L+N+PE | 48 V | 20-60 V | 100 A | REMA/Anderson/Customized |
| QC48-150 | 330-530 V, 47-63 Hz, 3L+PE | 48 V | 20-60 V | 150 A | REMA/Anderson/Customized |
| QC48-200 | 330-530 V, 47-63 Hz, 3L+PE | 48 V | 20-60 V | 200 A | REMA/Anderson/Customized |
| QC48-400 | 330-530 V, 47-63 Hz, 3L+PE | 48 V | 20-60 V | 200+200 A | REMA/Anderson/Customized |
| 80V Series | |||||
| QC80-50 | 90-264 V, 47-63 Hz, L+N+PE | 80 V | 30-100 V | 50 A | REMA/Anderson/Customized |
| QC80-100 | 330-530 V, 47-63 Hz, 3L+PE | 80 V | 30-100 V | 100 A | REMA/Anderson/Customized |
| QC80-150 | 330-530 V, 47-63 Hz, 3L+PE | 80 V | 20-110 V | 150 A | REMA/Anderson/Customized |
| QC80-200 | 330-530 V, 47-63 Hz, 3L+PE | 80 V | 20-110 V | 200 A | REMA/Anderson/Customized |
| QC80-400 | 330-530 V, 47-63 Hz, 3L+PE | 80 V | 20-100 V | 200+200 A | REMA/Anderson/Customized |
| 120V Series | |||||
| QC120-50 | 90-264 V, 47-63 Hz, L+N+PE | 120 V | 30-132 V | 50 A | REMA/Anderson/Customized |
| QC120-100 | 330-530 V, 47-63 Hz, 3L+PE | 120 V | 60-200 V | 100 A | REMA/Anderson/Customized |
| QC120-150 | 330-530 V, 47-63 Hz, 3L+PE | 120 V | 60-200 V | 150 A | REMA/Anderson/Customized |
| QC120-200 | 330-530 V, 47-63 Hz, 3L+PE | 120 V | 60-200 V | 200 A | REMA/Anderson/Customized |
1. All specifications shown above are subject to change during products improving at any time without prior notice.
2. For other batteries not listed above, customization is also available.
